Small Block Chevy 283, 350 & 400 Serpentine Conversion Kit

All Inclusive WRAPTOR™ 8 Track Serpentine System for Chevy Small Block engines with 140 Amp alternator, GM Type II Power Steering Pump and Peanut Style AC compressor. CVF Racing's 8 Rib Serpentine pulleys increase grip, reduce stretching and prevent slipping compared to traditional 6 Rib designs. Spring loaded Gates tensioner ensures proper tension during hard acceleration and deceleration while compensating for belt stretch. Places alternator on the driver's side above the power steering pump.

Exclusive Carbon Fiber Wraptor Includes Authentic Carbon Fiber cut outs on main bracket and pulleys available in 5 different unique colors.

ALL INCLUSIVE KIT INCLUDES:

• 140 Amp Chrome 1-Wire CS130 Alternator*
• 35 GMP Electric Water Pump*
• Chrome AC Compressor
• AC Compressor Clutch Cover
• Chrome Plated Aluminum GM Type II Power Steering Pump
• Remote Mount Reservoir with Bracket
• Premium 8 Rib Belt*
• Crank Pulley*
• Crank Pulley Spacer*
• Alternator Pulley & Cover*
• Power Steering Pulley
• One Piece Billet Aluminum Bracket*
• Universal Alternator Fan*
• Spring Loaded Tensioner
• Idler Pulleys with Caps*

APPLICATION NOTES:

• Works with either Mechanical or Electric fuel Pump
• Requires Electric Fan
• Works with either Standard or Camel Hump/Fuelie Heads
• Power Steering Lines from pump to reservoir not included
• Compatible with Hydroboost

IF ORDERING WITHOUT ACCESSORIES, PLEASE SEE THE REQUIREMENTS BELOW:

• Alternator - GM CS130 Style Alternator with 6-12 O'clock mounting and 6.6" bolt spacing
• Power Steering Pump - GM Type II Pump
• Compressor - Peanut Style (7B10) Compressor with 8 Rib Clutch
