The Patriot

Big Block Chevy 396 - 427 - 454 Engine Serpentine Conversion Kit

Make your engine stand out from the crowd while supporting our great nation! The main Wraptor plate has been dipped and then coated with CVF's exclusive Ceramic Clear Coat providing a long lasting corrosion resistant finish! No yellowing. No Flaking. Ever.

All Inclusive WRAPTOR™ 8 Track Serpentine System for Chevy Small Block engines with 140 Amp alternator, GM Type II Power Steering Pump and Peanut Style AC compressor. CVF Racing's 8 Rib Serpentine pulleys increase grip, reduce stretching and prevent slipping compared to traditional 6 Rib designs. Spring loaded Gates tensioner ensures proper tension during hard acceleration and deceleration while compensating for belt stretch. Places alternator on the driver's side above the power steering pump.

ALL INCLUSIVE KIT INCLUDES:

• High Flow Aluminum Water Pump*
• 140 Amp Chrome 1-Wire CS130 Alternator*
• Chrome Plated AC Compressor
• AC Compressor Clutch Cover
• Chrome Plated Aluminum GM Type II Power Steering Pump
• Remote Mount Reservoir with Bracket
• Gates Premium 8 Rib Belt*
• Water Pump Pulley & Cover*
• Crank Pulley*
• Crank Pulley Spacer*
• Alternator Pulley & Cover*
• Power Steering Pulley
• One Piece Billet Aluminum Bracket with Patriotic Finish*
• Universal Alternator Fan*
• All Mounting Hardware*

**Included with all configurations

AVAILABLE OPTIONS:

• Polished, Black, Ceramic Clear Coat, or Black Diamond Pulley Finish
• GM Type 2, Hydroboost, or Saginaw Power Steering
• 140 or 300 AMP Alternator

APPLICATION NOTES:

• Works with either Mechanical or Electric fuel Pump
• Works with either Mechanical or Electric fan (Highly Recommended)
• Works with either Standard or Tall Deck
• Power Steering Lines from pump to reservoir sold separately
• Reverse Rotation Water Pump (Included)
• Compatible with Hydroboost
• Compatible with Big Block 396 - 402 - 427 - 454 - 502 - 572 - 632 Engines

IF ORDERING WITHOUT ACCESSORIES, PLEASE SEE THE REQUIREMENTS BELOW:

• Alternator - GM CS130 Style Alternator with 6-12 O'clock mounting and 6.6" bolt spacing
• Power Steering Pump - GM Type II Pump
• Compressor - Peanut Style (7B10) Compressor with 8 Rib Clutch
• Water Pump - 5.62" Tall, Reverse Rotation, 5/8" Pilot and Lower Radiator Hose on Passenger Side
